R32 Swimming pool Series

R32 Swimming pool Series Heat Pump

Anti-corrosion design, suitable for swimming pool use.

Water Proof IPX 4

Speak To An Heat Pump Specialist

Data Details

Product Parameter

Power Source

Electric

Capacity

7kW/9kW/11kW/15kW/18kW/

21kW/28kW

Compressor

R32 DC Invertor

Controller

Touch Screen + WIFI

Max Hot Water Temperature

40°

Certification

Erp A+++，CE，EMC，

Keymark，MCS，Rohs

Specificities

Unique Features

WIFI, 4G, APP remote control

optional 4-inch touch screen controller

Stylish Appearance Design

Mouldable front panel, high-end fashion styling, can be customised

Corrosion Protection

Anti-corrosion design of the machine body

Extreme Body Machine And Weight

Outstanding container capacity – saves on shipping costs and doesn’t take up much space

Low Temperature Operation

Perfect operation at low temperatures – under 25°C

Full DC Inverter Technology

GMCC R32 Full DC Inverter Two-Stage Compressor + DC Fan

Application

Suitable scenarios

Swimming Pool

Differentiating Factors

Unique Product Advantages

EVI R32 Swimming pool Series

Low Noise Reduction Technology

Key Components Material

Swimming Pool Use Area

Famous Components Brand

Speak To A Heat Pump Specialist

SERVICE & SUPPORT

What Can We Serve For You ?

Technical Support

We provide HTA training system – Hetapro training academics to help you achieve product use, market analysis, competitive research, etc.

Custom Solution

Tailor-made for you, our solution guarantees optimal results with custom Appearance, performance, systems, etc.

Training System

HTA Training System – Hetapro Training Academic, helping you with product selection, installation and commissioning and maintenance training.

Warranty

3 years, part of components free.

Specification

Model			7.5kW	11kW	14kW	19kW	23kW
Power supply			220-240V~, 1Ph, 50Hz
* Performance at Air 26℃, Water 28℃, Humidity 80%
Heating capacity		kW	2.00~7.50	4.80~11.80	5.4~14.30	7.1~19.80	7.80~23.00
Power input		kW	0.16~1.16	0.36~2.00	0.42~2.33	0.60~3.17	0.67~3.83
COP			6.22~12.50	6.18~12.70	6.15~12.80	6.08~12.50	6.00~11.60
* Performance at Air 15℃, Water 28℃, Humidity 70%
Heating capacity		kW	1.30~5.40	3.50~8.70	4.35~10.30	5.10~14.63	5.80~16.30
Power input		kW	0.16~1.15	0.48~1.88	0.54~2.02	0.65~2.73	0.74~3.80
COP			4.70~8.00	5.18~8.10	5.10~8.00	5.08~7.90	4.30~7.80
* Performance at Air 35℃, Water 26℃, Humidity 40%
Cooling capacity		kW	1.70~4.60	4.50~6.10	4.80~7.00	4.00~10.20	4.30~12.50
Power input		kW	1.00~0.23	0.60~1.38	0.67~1.67	1.15~2.15	1.26~2.43
EER			4.60~7.50	4.36~7.30	4.20~7.20	3.10~4.93	3.40~5.10
Max. power input		kW	2.50	2.60	2.80	4.30	4.70
Max. current		A	12.00	14.00	15.00	19.00	21.00
Water flow		m³/h	2~4	4~6	5~7	6~8	7~9
Operation temperature range		ºC	-10~45
Setting water temperature range		ºC	8~40
Advised swimming pool size		m³	16~32	28~55	32~65	60~120	65~130
Refrigerant pressure (Max. / Min.)		MPa	1.6 / 4.5
Refrigerant	Type		R32
Refrigerant	Charged volume	g	600	1000	1000	2500	2500
Compressor Type			DC inverter, rotary
Fan motor type			Brushless DC
Sound pressure level	@1m	dB(A)	39~50	39~51	42~53	43~54	45~58
Sound pressure level	@10m	dB(A)	19~30	26~35	22~33	26~38	25~37
Water pipe connection		mm	Φ50	Φ50	Φ50	Φ50	Φ50
Controller			Internal wire controller
Water resistance			IPX4
Dimension (L×W×H)	Unit	mm	880×383×632	951×368×719		1090×421×728
Dimension (L×W×H)	Packing	mm	915×446×750	996×481×842		1155×540×868
Loading QTY	20GP/40HQ		90/192	58/154		42/115
Weight	Net	kg	36	50	50	79	79
Weight	Gross	kg	45	62	62	91	91
Notes:The specification may be changed for product improvement, please refer to the nameplate of product.
